Technical parameters
1. Main steel structure: welded H steel
2. Column and Beam: Welding H section steel
3. Purlin: C section steel
4. Wall and Roof insulation: Single color sheet , Colour sheet with Glass-wool , EPS Sandwich panel , for customers choose;
5. Crane: 5T,10T,15T,ect.
6. Door: Sliding Door, 50mm EPS Sandwich panel;
7. Window: Aluminum Window. Tie bar: Q235B round tube
8. Brace: round steel
9. Lateral and column bracing: round steel
10. Knee brace: hot- rolled angle steel
11. Trims,flashing: color steel sheet
12. Gutter:color steel sheet
13. Downpipe: PVC
14. Door: sandwich panel door
15. Window: Aluminum window (single glass)
| Main structure frame | Steel Welded H Section and Hot rolled H section |
| Secondary frame | Galvanized C section,tie bar,knee bracing,edge cover ect. |
| Purlin | galvanized C Section or Z Section Channel |
| Roof and Wall Cladding | EPS& Rock Wool& Fiberglass & PU Sandwich Panel or Corrugated Steel Sheet |
| Tie Rod | Circular Steel Tube |
| Brace | Round Bar |
| Column & Transverse Brace | Angle Steel or H Section Steel or Steel Pipe |
| Knee Brace | Angle Steel |
| Roof Gutter | Color Steel Sheet |
| Rainspout | PVC Pipe |
| Door | Sliding Sandwich Panel Door or Metal Door |
| Windows | PVC/Plastic Steel/Aluminum Alloy Window |
| Connecting | High Strength Bolts |
| Packing | Decided by you , loaded into 1X 40ft GP,1X20 ft GP,1X40 ft HQ |
| Drawing | We can make the design and quotation according to your require or your drawing |
Our production equipment
Technical Parameters
| Item Name | steel structures workshop |
| Main Material | Q235/Q345 Welded H Beam and Hot Rolled Section Steel |
| Surface | Painted or Hot Dip Galvanized |
| Roof & Wall Panel | EPS Sandwich panel /Single Corrugated Steel Sheet/ Colour sheet with Glass-wool, for customers choose |
| Window | PVC Steel or Aluminum Alloy |
| Door | Sliding Door or Rolling Up Door |
| Service | Design, Fabrication and Installation |
| We can make quotation according to customer's drawing or requirement; (size by length/width/height and wind speed), offering a free design drawing and all detailed drawings for installation. |
| Design software: Auto CAD,PKPM,MTS,3D3S, Tarch, Tekla Structures(Xsteel)V12.0.etc |
| Packing | According to customer's requirement |
| Load into 40/20GP,40HQ or 40OT |
Our excellent design team will design the steel structure workshop warehouse for you. If you give the following information, we will give you an satisfactory drawing.
1 Location (where will be built? ) _____country, area
2 Size: Length*width*height _____mm*_____mm*_____mm
3 wind load (max. Wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. Snow height)
_____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; If not, the metal steel sheets will be ok. The cost of the latter will be much lower than that of the former.
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. Lifting weight____tons; Max. Lifting height _____m
